579R 【Low VOC】Acetate cloth adhesive tape
This is a low VOC (Volatile Organic Compounds) tape that is environmentally and human health friendly.
Suitable for binding electric wires of home appliances and automobiles, and for fixing automobile parts, for which low VOC measures are required.
Adhesion to backing is strong and is not easily removed from the terminal when wound, making it ideal for winding and binding.
Features
- Environmentally friendly product with reduced VOC.
- The adhesive does not intentionally use any of the 13 VOC substances designated by the Ministry of Health, Labor and Welfare, including toluene and xylene.
- Conforms well to uneven surfaces.
- Suitable for winding as it has high peel adhesion to its own backside and is hard for the terminal to peel off.
- №579S with release liner.
Structure
Purpose
- Binding of wiring harnesses.
- Insulation and fixing of automotive parts and various electronic parts.
Characteristics
| Total thickness (mm) | 0.23 | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Standard colors | White, Black, Blue | ||||||||||
| Standard width (mm) | － | ||||||||||
| Standard length (m) | 30 | ||||||||||
| Peel adhesion (N/25mm) The first adhesive side (the inner side) / The second side (the outer side) |
14.00 | ||||||||||
| Tensile strength(N/25㎜) | 150 | ||||||||||
| Elongation(%) | 20 | ||||||||||
| Breakdown voltage (kV) | － | ||||||||||
| Shear adhesive strength (N/400㎟) | － | ||||||||||
| Measurement conditions and other measurement items | － | ||||||||||
| Standards and Certification | － | ||||||||||
| Remarks | This product does not intentionally use any of the 10 Rohs2 directive substances. | ||||||||||
Notes
The above data are reference values measured by JIS or our test method and are not guaranteed values. Customers are advised to conduct tests in advance and use the product only after thoroughly confirming that it conforms to the intended use. Do not apply to the human body. Wipe off dust, oil, and moisture from the surface to be applied, and press firmly to apply. When storing, avoid direct sunlight, high temperature and high humidity. Products and product specifications are subject to discontinuation or change without notice.
For more information about our products, please contact the nearest branch or sales office.
