Compared to conventional cloth tape, this cloth tape is lightweight and compact, making it easy to carry.
It can be easily cut by hand, yet is flexible and has strong adhesion.
Non-packaged products (without pillow wrapping) are also available to reduce waste and improve workability for the environment.
-
25
-
38
-
50
-
60
-
75
-
100
Features
- Light and compact.
- Can be easily cut by hand and smoothly rewound.
- Non-packaged products (without pillow wrapping) are also available to reduce waste and improve workability for the environment.
Structure
Acquired Mark
Purpose
- General packaging.
- Cardboard packaging.
- Repairing and binding at home and other places.
Characteristics
| 1590(0.20) | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Total thickness (mm) | 0.2 | ||||||||||
| Standard colors | Cream | ||||||||||
| Standard width (mm) | 25、38、50、60、75、100 | ||||||||||
| Standard length (m) | 25, 50 (50, 75 mm width only) | ||||||||||
| Peel adhesion (N/25mm) The first adhesive side (the inner side) / The second side (the outer side) |
9.81 | ||||||||||
| Tensile strength(N/25㎜) | 135 | ||||||||||
| Elongation(%) | 9 | ||||||||||
| Breakdown voltage (kV) | － | ||||||||||
| Shear adhesive strength (N/400㎟) | － | ||||||||||
| Measurement conditions and other measurement items | － | ||||||||||
| Standards and Certification | － | ||||||||||
| Remarks | This product does not intentionally use any of the 10 Rohs2 directive substances. | ||||||||||
Quantity
| Size | 25mmx 25m | 38mmx 25m | 50mmx 25m | 60mmx 25m | 75mmx 25m | 100mmx 25m | 50mmx 50m | 75mmx 50m |
|---|---|---|---|---|---|---|---|---|
| Quantity | 60 rolls | 48 rolls | 30 rolls | 30 rolls | 24 rolls | 18 rolls | 30 rolls | 18 rolls |
JAN Code
| 1590 | 50mm x 25M | 50mm x 50M |
|---|---|---|
| Cream(Pillow wrapping) | 4964833159020 | 4964833159051 |
Notes
The above data are reference values measured by JIS or our test method and are not guaranteed values. Customers are advised to conduct tests in advance and use the product only after thoroughly confirming that it conforms to the intended use. Do not apply to the human body. Wipe off dust, oil, and moisture from the surface to be applied, and press firmly to apply. When storing, avoid direct sunlight, high temperature and high humidity. Products and product specifications are subject to discontinuation or change without notice.
For more information about our products, please contact the nearest branch or sales office.
